Cov khoom lag luam
Lub tshuab ntsuas hluav taws xob hydraulic, nrog lub German imported hydraulic system ua cov ntsiab lus tsim tau tiav los ntawm cov khoom siv tsim tau tiav, rov ua haujlwm zoo thiab cov khoom siv tau kuaj.
Daim Ntawv Thov Kev Pab Cuam
Hauv kev soj ntsuam kev kuaj xyuas zoo ntawm cov khoom lag luam hlau, tusTester Hydraulic Tensertuaj yeem ua tiav lub zog tensile thiab kev sim elongation ntawm ib qho kev txhawb nqa ntawm cov kab tsis sib xws li ntawm 10 feeb. Los ntawm cov qauv siv cov khoom siv tsis zoo no thiab khoo scannode lees paub system, cov khoom siv tuaj yeem phim cov qauv kev qhia thiab cov qauv xeem. Nws tuaj yeem daws cov qauv 60 cov qauv ib teev, uas yog 300% ntau dua li cov khoom siv hauv ib txwm muaj. Tom qab pawg loj tshaj plaws qhia cov khoom siv no, tus nqi ntawm kev ua haujlwm tau yooj yim los ntawm cov teeb meem siv tau los ntawm kaum lab yuan.
Nyob rau hauv lub Hoobkas soj ntsuam ntawm lub cev cov txheej txheem los ntawm tsheb tuam ntxhab, cov kev ntsuam xyuas Tensile yog qhov yuav tsum tau txheeb xyuas lub zog ntawm vuam cov ntsiab lus thiab cov kev sib txuas sib txuas. Qhov kev ntsuas kev sim ua haujlwm ntawm cov kws sim siab tenser muaj peev xwm simulation kev lag luam thaum lub sijhawm 10Hz, raug rau kev ua haujlwm rog ntawm cov khoom siv. Tom qab qee qhov kev lag luam lub tsheb tshiab tau txais kev lag luam no, kev qaug zog lub neej ntawm lub tsheb lub cev tau luv los ntawm 72 teev mus rau 48 teev. Nyob rau tib lub sijhawm, qhov sib xws ntawm cov ntaub ntawv xeem thiab kev sim tsheb tiag tiag tau txhim kho rau 92%, txo tus nqi R & D.
Kev Nyab Xeeb Kev Nyab Xeeb
Ntau-qib kev tiv thaiv kev ruaj ntseg
Cov cuab yeej siv tau nruab nrog peb kev nyab xeeb tshuab: kev tiv thaiv txhua yam, software ntau dhau kev tiv thaiv thiab khawm ceev ceev. Thaum lub zog xeem tau tshaj 11 {{0% ntawm cov teeb tsa sab sauv, lub hydraulic yuav daws tsis pub dhau 0.1 vib nas this. Qhov chaw xeem yog muaj 3 hli tuab tempered iav tiv thaiv npog. Thaum lub npog tiv thaiv tau qhib, cov cuab yeej siv tam sim ntawd nres khiav kom tsis txhob tawg tawg los ntawm ya thaum ya tawm thaum cov qauv tawg. Ib qho ntxiv, cov khoom siv tau dhau cov kev ruaj ntseg thoob ntiaj teb muaj ntawv pov thawj xws li CE thiab ISO 13485, thiab ua raws li kev tswj hwm kev nyab xeeb.
Ergonomic Tsim
Qhov siab ntawm kev ua haujlwm console tuaj yeem hloov kho nyob rau hauv thaj tsam ntawm 750mm txog 900mm kom tau raws li kev siv cov kev siv ntawm cov neeg ua haujlwm sib txawv. Cov kev hloov hloov txhim kho kev hloov kho sai sai, thiab ib tus neeg tuaj yeem ua tiav cov khoom siv hloov thiab ntsuas hluav taws xob tsis pub dhau 3 feeb. Lub sijhawm ua suab nrov ntawm cov khoom lag luam yog tsawg dua lossis sib npaug ntawm 65db, uas yog qhov qis dua qhov nruab nrab ntawm 80db, tsim ib puag ncig ua haujlwm rau chav kuaj.
Khoom siv tsis sib haum
|
Tus qauv |
Bt -300 b |
Bt -600 b |
Bt -1000 b |
||
|
Qhov siab tshaj plaws yuam (kn) |
300 |
600 |
1000 |
||
|
Qib Kev Qib Siab Qib |
1 |
||||
|
Kev sau cov txheej txheem |
Hais Tus Log Sensor |
||||
|
Piston stroke (hli) |
200 |
||||
|
Clamping txoj kev |
HYDRAULIC |
||||
|
Kuaj cov qauv |
Microcomputer Servo Tswj |
||||
|
Kev kuaj qhov chaw ntsuas (mm) |
600 |
||||
|
Qhov chaw kuaj Tensile (hli) |
700 |
||||
|
Tag nrho cov hwj huam (kw) |
1.5 |
||||
|
Compression Platen (hli) |
Φ148 |
Φ198 |
Φ225 |
||
|
Hloov piv qhov qauv clamping ntau (mm) |
Φ10-30 |
Φ13-40 |
Φ13-40 |
||
|
Ca piv Camping ntau (mm) |
0-10 |
0-15 |
0-20 |
||
|
Dabtsi yog khoov cov paj lug puab (mm) |
50-300 |
||||
|
Dabtsi Yog Khoov Lub Plawv \/ Lo Ntxhae Inch (Mm) |
50/50 |
||||
|
Tus naj npawb ntawm cov kab (screws) |
6 Kem |
||||
|
Mainframe Qhov Ntev (MM) |
810*560*1910 |
880*570*2050 |
940*640*2250 |
||
|
Tus tswv tsev hnyav (kg) |
≈1620 |
≈2000 |
≈2600 |
||
|
Tswj Txee Loj (hli) |
1010*640*840 |
||||
|
Tswj txee phaus (kg) |
150 |
||||
